Schematic Caterpillar 216B3, 226B3, 236B3, 242B3, 252B3, 247B3, 257B3, 259B3 | UENR0254-04

THIS SCHEMATIC IS FOR THE 216B3, 226B3, 236B3, 242B3, AND 252B3 SKID STEER LOADER, 247B3, AND 257B3 MULTI-TERRAIN LOADER AND 259B3 COMPACT TRACK LOADER ELECTRICAL SYSTEM
VOLUME 1 of 2: CAB WIRING
MEDIA NUMBER: UENR0254-04
SCHEMATIC PART NUMBER: 326-6377, CHANGE: 00, VERSION: –

THIS SCHEMATIC IS FOR THE 216B3, 226B3, 236B3, 242B3, AND 252B3 SKID STEER LOADER, 247B3, AND 257B3 MULTI-TERRAIN LOADER, AND 259B3 COMPACT TRACK LOADER ELECTRICAL SYSTEM
VOLUME 2 of 2: CHASSIS AND ENGINE WIRING
MEDIA NUMBER: UENR0254-04
SCHEMATIC PART NUMBER: 326-6377, CHANGE: 00, VERSION: –
