Kobelco SK850LC-9 Excavator S5LY0006E04 (Preview)
**INDEX**
**Model:** SK850LC-9
**Region:** NA
| Book Code No. / Distribution Year-Month | Category | Title | Index No. |
| :— | :— | :— | :— |
| S5YN0129E01 / 2012-12 | **SPECIFICATIONS** | OUTLINE | 1 |
| S5LY0206E01 / 2014-05 | | SPECIFICATIONS | 2 |
| S5LY0306E01 / 2014-05 | | ATTACHMENT DIMENSIONS | 3 |
| S5LY1106E01 / 2012-12 | **MAINTENANCE** | TOOLS | 11 |
| S5LY1206E01 / 2015-11 | | STANDARD MAINTENANCE TIME SCHEDULE | 12 |
| S5LY1306E02 / 2014-10 | | MAINTENANCE STANDARD AND TEST PROCEDURE | 13 |
| S5LY2106E01 / 2014-05 | **SYSTEM** | MECHATRO CONTROL SYSTEM | 21 |
| S5LY2206E01 / 2014-05 | | HYDRAULIC SYSTEM | 22 |
| S5LY2306E01 / 2014-05 | | ELECTRIC SYSTEM | 23 |
| S5LY2406E01 / 2014-05 | | COMPONENTS SYSTEM | 24 |
| S5LY2506E01 / 2012-12 | | AIR-CONDITIONER SYSTEM | 25 |
| S5YN3129E01 / 2012-12 | **DISASSEMBLING** | DISASSEMBLING & ASSEMBLING | 31 |
| S5LY3206E01 / 2014-05 | | ATTACHMENT | 32 |
| S5LY3306E01 / 2012-12 | | UPPER STRUCTURE | 33 |
| S5LY3406E01 / 2012-12 | | TRAVEL SYSTEM | 34 |
| S5LY4606E01 / 2012-12 | **TROUBLESHOOTING**| BY ERROR CODES | 46 |
| S5LY4706E01 / 2012-12 | | BY TROUBLE | 47 |
| S5LY5106E02 / 2016-11 | **E/G** | ENGINE | 51 |
| | | APPLICABLE MACHINES | — |
